Flex10Box-Pouch Fill and Seal Machine

NEW INNOVATION IN FLEXIBLE PACKAGING
The box-pouch is the newest trend in the market. It has many names: flat bottom pouch, the quad seal bottom pouch, block bottomed pouch, side gusset pouch… This pouch is welded in four corners and it has a completely flat bottom so it can stand on its own.
Download Brochure

Key Features

The Flex10 Box-pouch fill & seal machine can pack almost anything into a box-pouch. With high efficiencies, a compact footprint, a wide range of bag sizes, decreased downtime, the Flex10 will surely satisfy your box-pouch packaging needs!

Benefits

  • Washdown Icon

    WASHDOWN STRUCTURE

    The washdown structure allows for cleaning the machine with a spray of water.

  • Bottom Pouch Support Icon

    BOTTOM POUCH SUPPORT

    Conveyor system provides additional support for heavier pouches.

  • Nitrogen Gas Icon

    NITROGEN GAS FLUSHING

    Fills the pouch with nitrogen before sealing the pouch. Keeps the product fresh.

  • Pouch Deflator Icon

    POUCH DEFLATOR

    Eliminates excessive air from the pouch. Removing oxygen from the pouch keeps your product fresh.

  • Dust Shrouder Icon

    DUST SHROUDER

    Remove excess dust generated during filling stage. For non-free-flowing products.

  • Vibratory Settler

    VIBRATORY SETTLER

    Provides improved product settling inside the pouch.

  • Code and Date Printer Icon

    CODE/DATE PRINTER

    Prints a code/date on the pouch prior to pouch opening. Includes camera verification.


Flex10 SimluationFLEX10 SIMULATION

BOX-POUCH PACKAGING OPERATION REVIEW

The Flex10 is assembled from carefully chosen or designed and produced parts in order to provide our clients with efficiently optimized Box-Pouch packaging process that allows for maximum efficiency.At Tishma Technologies, we strive to provide transparency and full understanding of machine’s operation to all of our current and potential clients. That is why each of our projects is accompanied by a detailed 3D simulation of the packaging machine’s sequence of operations. Take a look at the simulation and get familiar with the way Flex10 operates.

Wide Box Range

WIDE BOX-POUCH SIZE RANGE

SPEED UP TO 60 BOX-POUCHES PER MINUTE

Flex10 is capable of running a variety of box-pouch types within its box-pouch size range regardless of material finish! Whatever box-pouch type you choose for your product, Flex10 is able to handle it.



PRODUCT INFEED OPTIONS

AUGER FILLER Suitable for non free-flowing products and products that generate dust like coffee, flour and other similar powders.
MULTI-HEAD WEIGHER / SCALE Allows more packs per weight of product, and more packs per shiſt due to improvement of weighing accuracy. Suitable for complex, multiple component products like cereal mix.
HIGH-SPEED CONVEYOR Recommend for transferring products from one location to another quickly.
MAGNEMOTION CONVEYOR WITH PICK AND PLACE OPERATION Flex10 is available with optional MagneMotion conveyor with pick and place operation that delivers products to the filling station.
ROBOTIC INFEED Recommended for sensitive and fragile products that demand delicate product handling, like electronics, or glass based products.
VIBRATORY COUNTER / FILLER Suitable for packaging application where measuring precision and accuracy are crucial and for products that are uneven, such as wafers, grains, dried food, nuts and fruits.
VOLUMETRIC CUP FILLER Recommended for free-flowing solids like rice, candies or frozen peas or powders that don’t generate dust.

UP/DOWNSTREAM OPTIONS

LABELER Automatically apply labels to pouches and/or cases.
CHECKWEIGHER Improve weight control and verification.
PALLETIZER Stack ready-to-ship pallets. Robotic and traditional palletizer are available.
REJECT STATION Discover and remove scrap pouches automatically.
METAL DETECTOR Detect all unwanted metal particles.
CASE PACKER Pack pouches in a variety of case/boxes

BAG OPTIONS

SEALED BOX-POUCH Sealed pouch is perfect for single portion products and lower net weigh packaging format.
WINDOWED BOX-POUCH Window allows consumer to see the product, especially important for organic products.
RESEALABLE / ZIPPER BOX-POUCH Perfect for packaging with higher net weight. Zipper keeps the product fresh until the next use. Zipper can be on the front or back of a pouch.
MATERIAL FINISH POUCHES Metalized pouch, Clear Pouch, Kraft Paper Pouch, Rise Paper Pouch, Foil Pouch, Matte / Satin Pouch.

MODELS

MACHINE PITCH 10” (may adjust per bag size)
SPEED 60 PPM
DIMENSIONS Length: 190’’ Width: 93’’ Height: 92’’
POUCH SIZE RANGE Width: 4-10” Height: 6-12” Gussett: 1-4”
CONTROLS A. B. Compact Logic, A. B. PanelView HMI
SERVOS AND MOTORS Allan Bradley
INPUT VOLTAGE 240-480 V
INPUT AIR 80-90 PSI
